Appendix A
Auxiliary Functions
Auxiliary Functions
A–2
Introduction
Many CPU setup tasks involve the use of Auxiliary (AUX) Functions. The AUX
Functions perform many different operations, including clearing ladder memory,
displaying the scan time, and copying programs to EEPROM in the handheld
programmer. They are divided into categories that affect different system resources.
You can access the AUX Functions from DirectSOFT
or from the D2–HPP
Handheld Programmer. The manuals for those products provide step-by-step
procedures for accessing the AUX Functions. Some of these AUX Functions are
designed specifically for the Handheld Programmer setup, so they will not be
needed (or available) with the DirectSOFT package. Even though this Appendix
provides many examples of how the AUX functions operate, you should supplement
this information with the documentation for your choice of programming device.
Note, the Handheld Programmer may have additional AUX functions that are not
supported with the DL05 PLCs.
AUX Function and Description DL05
AUX 2* — RLL Operations
21 Check Program
22 Change Reference
23 Clear Ladder Range
24 Clear All Ladders
AUX 3* — V-Memory Operations
31 Clear V Memory
AUX 4* — I/O Configuration
41 Show I/O Configuration
AUX 5* — CPU Configuration
51 Modify Program Name
53 Display Scan Time
54 Initialize Scratchpad
55 Set Watchdog Timer
56 Set Communication Port 2
57 Set Retentive Ranges
58 Test Operations
59 Override Setup
5B HSIO Interface Configuration
5D Scan Control Setup
— supported
HP — Handheld Programmer function
AUX Function and Description DL05
AUX 6* — Handheld Programmer Configura-
tion
61 Show Revision Numbers
62 Beeper On / Off HP
65 Run Self Diagnostics HP
AUX 7* — EEPROM Operations
71 Copy CPU memory to
HPP EEPROM
HP
72 Write HPP EEPROM to CPU HP
73 Compare CPU to
HPP EEPROM
HP
74 Blank Check (HPP EEPROM) HP
75 Erase HPP EEPROM HP
76 Show EEPROM Type
(CPU and HPP)
HP
AUX 8* — Password Operations
81 Modify Password
82 Unlock CPU
83 Lock CPU
Purpose of
Auxiliary Functions
