Automationdirect.com DL05 User Manual

Appendix C
Inst. Execution Times
C–15
Instruction Execution Times
CPU Control Instructions
DL05
Instruction Legal Data Types Execute Not Execute
NOP None
1.1 ms 1.1 ms
END None
24.0 ms 24.0 ms
STOP None
10.0 ms 1.1 ms
RSTWDT None
5.9 ms 2.2 ms
NOT None
1.6 ms 1.6 ms
Program Control Instructions
DL05
Instruction Legal Data Types Execute Not Execute
FOR V, K
125.9 ms 14.5 ms
NEXT None
64.4 ms 64.4 ms
GTS K
27.5 ms 14.8 ms
SBR K
1.5 ms 1.5 ms
RTC None
25.7 ms 12.1 ms
RT None
21.2 ms 21.2 ms
MLS K (1–7)
35.2 ms 35.2 ms
MLR K (0–7)
30.9 ms 30.9 ms
Interrupt Instructions
DL05
Instruction Legal Data Types Execute Not Execute
ENI None
24.2 ms 2.7 ms
DISI None
9.4 ms 2.3 ms
INT O(0,1)
7.5 ms
–
IRTC None
0.9 ms 1.3 ms
IRT None
6.6 ms
–
Network Instructions
DL05
Instruction Legal Data Types Execute Not Execute
RX X, Y, C, T, CT, SP, S, $
V:Data Reg.
V:Bit Reg.
P:Indir. (Data)
P:Indir. (Bit)
852.0 ms
852.0 ms
852.0 ms
868.2 ms
868.2 ms
4.4 ms
4.4 ms
4.4 ms
4.2 ms
4.2 ms
WX X, Y, C, T, CT, SP, S, $
V:Data Reg.
V:Bit Reg.
P:Indir. (Data)
P:Indir. (Bit)
1614.0 ms
1614.0 ms
1614.0 ms
1630.0 ms
1630.0 ms
4.4 ms
4.4 ms
4.4 ms
4.4 ms
4.4 ms
CPU Control
Instructions
Program Control
Instructions
Interrupt
Instructions
Network
Instructions
