Automationdirect.com DL05 User Manual

Appendix C
Inst. Execution Times
C–3
Instruction Execution Times
Instruction Execution Times
Boolean Instructions
DL05
Instruction Legal Data Types Execute Not Execute
STR X, Y, C, T, CT, S, SP
2.0 ms 2.0 ms
STRN X, Y, C, T, CT, S, SP
2.3 ms 2.3 ms
OR X, Y, C, T, CT, S, SP
1.6 ms 1.6 ms
ORN X, Y, C, T, CT, S, SP
1.9 ms 1.9 ms
AND X, Y, C, T, CT, S, SP
1.4 ms 1.4 ms
ANDN X, Y, C, T, CT, S, SP
1.6 ms 1.6 ms
ANDSTR None
1.3 ms 1.3 ms
ORSTR None
1.3 ms 1.3 ms
OUT X, Y, C
6.8 ms 6.8 ms
OROUT X, Y, C
6.7 ms 6.7 ms
NOT None
1.6 ms 1.6 ms
PD X, Y, C
52.3 ms 53.0 ms
STRPD X, Y, C, T, CT, S, SP
20.2 ms 12.9 ms
STRND X, Y, C, T, CT, S, SP
20.1 ms 13.0 ms
ORPD X, Y, C, T, CT, S, SP
20.0 ms 12.6 ms
ORND X, Y, C, T, CT, S, SP
19.8 ms 12.7 ms
ANDPD X, Y, C, T, CT, S, SP
20.0 ms 12.6 ms
ANDND X, Y, C, T, CT, S, SP
19.9 ms 12.8 ms
SET 1st #: X, Y, C, S
2nd #: X, Y, C, S (N pt)
32.2 ms
14ms+3.1msxN
3.7 ms
4.7 ms
RST 1st #: X, Y, C, S
2nd #: X, Y, C, S (N pt)
34.4 ms
16+3.2xN
3.7 ms
4.7 ms
1st #: T, CT
2nd #: T, CT (N pt)
63.6 ms
39+6.7xN
3.7 ms
4.9 ms
PAUSE 1wd: Y
2wd: Y (N points)
23.4 ms
19.7+1.5xN
23.0 ms
19.5+1.4xN
Boolean
Instructions
