Installation, Wiring, and Specifications
External Power Requirements 95 – 240 VAC, 30 VA maximum,
Communication Port 1
9600 baud (Fixed), 8 data bits, 1 stop bit,
odd parity
K–Sequence (Slave)
DirectNET (Slave)
MODBUS (Slave)
Communication Port 2
9600 baud (default), 8 data bits, 1 stop bit,
odd parity
K–Sequence (Slave)
DirectNET (Master/Slave)
MODBUS (Master/Slave)
Non-sequence / print
Programming cable type D2–DSCBL
Operating Temperature
32 to 131° F (0 to 55_ C)
Storage Temperature
–4 to 158° F (–20 to 70_ C)
Relative Humidity 5 to 95% (non-condensing)
Environmental air No corrosive gases permitted
Vibration MIL STD 810C 514.2
Shock MIL STD 810C 516.2
Noise Immunity NEMA ICS3–304
Terminal Type Removable
Wire Gauge One AWG16 or two AWG18, AWG24 minimum
Input Voltage Range (Min. - Max.) 80 – 132 VAC, 47 - 63 Hz
Operating Voltage Range 90 – 120 VAC, 47 - 63 Hz
Input Current 8 mA @ 100 VAC (50Hz)
10 mA @ 100 VAC (60Hz)
Max. Input Current 12 mA @ 132 VAC (50Hz)
15 mA @ 132 VAC (60Hz)
Input Impedance
14K @50 Hz, 12K @60 Hz
ON Current/Voltage >6 mA @ 75 VAC
OFF Current/Voltage <2 mA @ 20 VAC
OFF to ON Response < 40 mS
ON to OFF Response < 40 mS
Status Indicators Logic Side
Commons 4 channels / common x 2 banks
Parameter Pulse Outputs, Y0 – Y1 Standard Outputs, Y2 – Y5
Min. - Max. Voltage Range 5 – 30 VDC 5 – 30 VDC
Operating Voltage 6 – 27 VDC 6 – 27 VDC
Peak Voltage < 50 VDC (7 kHz max. frequency) < 50 VDC
On Voltage Drop 0.3 VDC @ 1A 0.3 VDC @ 1A
Max Current (resistive) 0.5 A / pt. (1A / point for standard pt.) 1.0 A / point
Max leakage current
15 A @ 30 VDC 15 A @ 30 VDC
Max inrush current 2 A for 100 mS 2 A for 100 mS
Extenal DC power required 20 - 28 VDC max 150mA 20 - 28 VDC max 150mA
OFF to ON Response
<10 S < 10 S
ON to OFF Response
<30 S < 60 S
Status Indicators Logic Side Logic Side
Commons 6 channels / common x 1 banks
Fuses None None
D0–05AD
