Installation, Wiring,
and Specifications
2–33
Installation, Wiring, and Specifications
External Power Requirements 95 – 240 VAC, 30 VA maximum,
Communication Port 1
9600 baud (Fixed), 8 data bits, 1 stop bit,
odd parity
K–Sequence (Slave)
DirectNET (Slave)
MODBUS (Slave)
Communication Port 2
9600 baud (default), 8 data bits, 1 stop bit,
odd parity
K–Sequence (Slave)
DirectNET (Master/Slave)
MODBUS (Master/Slave)
Non-sequence / print
Programming cable type D2–DSCBL
Operating Temperature
32 to 131° F (0 to 55_ C)
Storage Temperature
–4 to 158° F (–20 to 70_ C)
Relative Humidity 5 to 95% (non-condensing)
Environmental air No corrosive gases permitted
Vibration MIL STD 810C 514.2
Shock MIL STD 810C 516.2
Noise Immunity NEMA ICS3–304
Terminal Type Removable
Wire Gauge One AWG16 or two AWG18, AWG24 minimum
Parameter High–Speed Inputs, X0 – X2 Standard DC Inputs X3 – X7
Min. - Max. Voltage Range 10.8 – 26.4 VDC 10.8 – 26.4 VDC
Operating Voltage Range 12 – 24 VDC 12 – 24 VDC
Peak Voltage 30 VDC (5 kHz maximum frequency) 30 VDC
Minimum Pulse Width
100 s
N/A
ON Voltage Level > 9.0 VDC > 9.0 VDC
OFF Voltage Level < 2.0 VDC < 2.0 VDC
Max. Input Current 6mA @12VDC, 13mA @24VDC 4mA @12VDC, 8.5mA @24VDC
Input Impedance
1.8 k @ 12 – 24 VDC 2.8 k @ 12 – 24 VDC
Minimum ON Current >5 mA >4 mA
Maximum OFF Current < 0.5 mA <0.5 mA
OFF to ON Response
<100 S
2 – 8 mS, 4 mS typical
ON to OFF Response
< 100 S
2 – 8 mS, 4 mS typical
Status Indicators Logic side Logic side
Commons 4 channels / common x 2 banks
Parameter Pulse Outputs, Y0 – Y1 Standard Outputs, Y3 – Y5
Min. - Max. Voltage Range 5 – 30 VDC 5 – 30 VDC
Operating Voltage 6 – 27 VDC 6 – 27 VDC
Peak Voltage < 50 VDC (7 kHz max. frequency) < 50 VDC
On Voltage Drop 0.3 VDC @ 1 A 0.3 VDC @ 1 A
Max Current (resistive) 0.5 A / pt., 1A / pt. as standard pt. 1.0 A / point
Max leakage current
15 A @ 30 VDC 15 A @ 30 VDC
Max inrush current 2 A for 100 mS 2 A for 100 mS
External DC power required 20 - 28 VDC Max 150mA 20 - 28 VDC Max 150mA
OFF to ON Response
< 10 s < 10 s
ON to OFF Response
< 30 s < 60 s
Status Indicators Logic Side Logic Side
Commons 6 channels / common x 1 banks
Fuses None (external recommended)
D0–05DD
General
Specifications
DC Input
Specifications
DC Output
Specifications
To Next Page
