Installation, Wiring,
and Specifications
2–35
Installation, Wiring, and Specifications
External Power Requirements 95 – 240 VAC, 30 VA maximum,
Communication Port 1
9600 baud (Fixed), 8 data bits, 1 stop bit,
odd parity
K–Sequence (Slave)
DirectNET (Slave)
MODBUS (Slave)
Communication Port 2
9600 baud (default), 8 data bits, 1 stop bit,
odd parity
K–Sequence (Slave)
DirectNET (Master/Slave)
MODBUS (Master/Slave)
Non-sequence / print
Programming cable type D2–DSCBL
Operating Temperature
32 to 131° F (0 to 55_ C)
Storage Temperature
–4 to 158° F (–20 to 70_ C)
Relative Humidity 5 to 95% (non-condensing)
Environmental air No corrosive gases permitted
Vibration MIL STD 810C 514.2
Shock MIL STD 810C 516.2
Noise Immunity NEMA ICS3–304
Terminal Type Removable
Wire Gauge One AWG16 or two AWG18, AWG24 minimum
Input Voltage Range (Min. - Max.) 80 – 132 VAC, 47 - 63 Hz
Operating Voltage Range 90 – 120 VAC, 47 - 63 Hz
Input Current 8 mA @100 VAC at 50 Hz
10 mA @100 VAC at 60 Hz
Max. Input Current 12 mA @132 VAC at 50 Hz
15 mA @132 VAC at 60 Hz
Input Impedance
14K @50 Hz, 12K @60Hz
ON Current/Voltage > 6 mA @ 75 VAC
OFF Current/Voltage < 2 mA @ 20 VAC
OFF to ON Response < 40 mS
ON to OFF Response < 40 mS
Status Indicators Logic Side
Commons 4 channels / common x 2 banks
Output Voltage Range (Min. - Max.) 15 – 264 VAC, 47 – 63 Hz
Operating Voltage 17 – 240 VAC, 47 – 63 Hz
On Voltage Drop 1.5 VAC (>50mA)
4.0 VAC (<50mA)
Max Current 0.5 A / point, 1.5 A / common
Max leakage current <4 mA @ 264 VAC
Max inrush current 10 A for 10 mS
Minimum Load 10 mA
OFF to ON Response 1 mS
ON to OFF Response 1 mS +1/2 cycle
Status Indicators Logic Side
Commons 3 channels / common x 2 banks
Fuses None (external recommended)
D0–05AA
General
Specifications
AC Input
Specifications
AC Output
Specifications
To Next Page
