Appendix C

Inst. Execution Times

C–16

Instruction Execution Times

Message Instructions

DL05

Instruction Legal Data Types Execute Not Execute

FAULT V:Data Reg.

V:Bit Reg.

K:Constant

65.0 ms

204.7 ms

4.4 ms

DLBL K – –

NCON K – –

ACON A – –

PRINT ASCII

631.0 ms 3.6 ms

RLL

PLUS

Instructions

DL05

Instruction Legal Data Types Execute Not Execute

ISG S

44.0 ms 41.1 ms

SG S

44.0 ms 41.1 ms

JMP S

76.0 ms 9.3 ms

NJMP S

77.4 ms 9.3 ms

CV S

42.1 ms 27.5 ms

CVJMP S

89.5 ms 17.6 ms

Drum Instructions

DL05

Instruction Legal Data Types Execute Not Execute

DRUM CT

840.0 ms 339.6 ms

EDRUM CT

753.2 ms 357.0 ms

Message

Instructions

RLL

PLUS

Instructions

Drum

Instructions
