5-28
Cisco Unified Communications Manager Managed Services Guide
OL-22523-01
Chapter 5 Cisco Unified Real-Time Monitoring Tool Tracing, PerfMon Counters, and Alerts
Performance Monitoring in RTMT
Cisco MGCP BRI Device
The Cisco Media Gateway Control Protocol (MGCP) Foreign Exchange Office (FXO) Device object
provides information about registered Cisco MGCP BRI devices. Table 5-21 contains information on
Cisco MGCP BRI device counters.
Table 5-20 Cisco Messaging Interface
Counters Counter Description
HeartBeat This counter represents the heartbeat of the CMI service. This incremental count
indicates that the CMI service is up and running. If the count does not increase
(increment), this means that the CMI service is down.
SMDIMessageCountInbound This counter represents the running count of inbound SMDI messages since the
last restart of the CMI service.
SMDIMessageCountInbound24Hour This counter represents the rolling count of inbound SMDI messages in the last
24 hours.
SMDIMessageCountOutbound This counter represents the running count of outbound SMDI messages since the
last restart of the CMI service.
SMDIMessageCountOutbound24Hour This counter represents the rolling count of outbound SMDI messages in the last
24 hours.
StartTime This counter represents the time in milliseconds when the CMI service started.
The real-time clock in the computer, which simply acts as a reference point that
indicates the current time and the time that has elapsed, in milliseconds, since the
service started, provides the basis for this time. The reference point specifies
midnight, January 1, 1970.
Table 5-21 Cisco MGCP BRI Device
Counters Counter Description
CallsCompleted This counter represents the total number of successful calls that were made from
this MGCP Basic Rate Interface (BRI) device
Channel 1 Status This counter represents the status of the indicated B-Channel that is associated
with the MGCP BRI device. Possible values: 0 (Unknown) indicates the status of
the channel could not be determined; 1 (Out of service) indicates that this channel
is not available for use; 2 (Idle) indicates that this channel has no active call and
is ready for use; 3 (Busy) indicates an active call on this channel; 4 (Reserved)
indicates that this channel has been reserved for use as a D-channel or for use as
a Synch-Channel for BRI.
Channel 2 Status This counter represents the status of the indicated B-Channel that is associated
with the MGCP BRI device. Possible values: 0 (Unknown) indicates the status of
the channel could not be determined; 1 (Out of service) indicates that this channel
is not available for use; 2 (Idle) indicates that this channel has no active call and
is ready for use; 3 (Busy) indicates an active call on this channel; 4 (Reserved)
indicates that this channel has been reserved for use as a D-channel or for use as
a Synch-Channel for BRI.
