Page #751 background image
7-109
Cisco Unified Communications Manager Managed Services Guide
OL-22523-01
Chapter 7 Cisco Management Information Base
CISCO-CCM-MIB
2—Media Termination Point
3—Transcoder
4—Conference Bridge
5—Music On Hold
1.3.6.1.4.1.9.9.156.2.0.6 ccmRouteListExhausted
1.3.6.1.4.1.9.9.156.2.0.7 ccmGatewayLayer2Change
1.3.6.1.4.1.9.9.156.2.0.8 ccmMaliciousCall
1.3.6.1.4.1.9.9.156.2.0.9 ccmQualityReport
1.3.6.1.4.1.9.9.156.2.0.10 ccmTLSConnectionFailure
Dynamic Table Objects
Table 7-3 lists the objects that are populated only if the Cisco Unified Communications Manager service
is up and running or the local Cisco Unified Communications Manager service in the case of a Cisco
Unified Communications Manager cluster configuration.
Table 7-3 CISCO-CCM-MIB Dynamic Tables
Object Content
ccmTable This table stores the version and installation ID for the local Cisco
Unified CM. The table also stores information about all the Cisco
Unified CMs in a cluster that the local Cisco Unified CM knows about
but shows “unknown” for the version detail. If the local Cisco Unified
CM is down, the table remains empty, except for the version and
installation ID values.
ccmPhoneFailed,
ccmPhoneStatusUpdate,
ccmPhoneExtn, ccmPhone,
ccmPhoneExtension
For the Cisco Unified IP Phone, the number of registered phones in
ccmPhoneTable should match Cisco Unified Communications
Manager/RegisteredHardware Phones perfmon counter. The
ccmPhoneTable includes one entry for each registered, unregistered, or
rejected Cisco Unified IP Phone. The ccmPhoneExtnTable uses a
combined index, ccmPhoneIndex and ccmPhoneExtnIndex, for relating
the entries in the ccmPhoneTable and ccmPhoneExtnTable.
ccmCTIDevice,
ccmCTIDeviceDirNum
The ccmCTIDeviceTable stores each CTI device as one device. Based
on the registration status of the CTI Route Point or CTI Port, the
ccmRegisteredCTIDevices, ccmUnregisteredCTIDevices, and
ccmRejectedCTIDevices counters in the Cisco Unified
Communications Manager MIB get updated.
ccmSIPDevice The CCMSIPDeviceTable stores each SIP trunk as one device.
