5-29
Cisco Unified Communications Manager Managed Services Guide
OL-22523-01
Chapter 5 Cisco Unified Real-Time Monitoring Tool Tracing, PerfMon Counters, and Alerts
Performance Monitoring in RTMT
Cisco MGCP FXO Device
The Cisco Media Gateway Control Protocol (MGCP) Foreign Exchange Office (FXO) Device object
provides information about registered Cisco MGCP FXO devices. Table 5-22 contains information on
Cisco MGCP FXO device counters.
Cisco MGCP FXS Device
The Cisco MGCP Foreign Exchange Station (FXS) Device object provides information about registered
Cisco MGCP FXS devices. One instance of this object gets created for each port on a Cisco Catalyst
6000 24 port FXS Analog Interface Module gateway. For example, a fully configured Catalyst 6000
Analog Interface Module would represent 24 separate instances of this object. Table 5-23 contains
information on Cisco MGCP FXS device counters.
DatalinkInService This counter represents the state of the Data Link (D-Channel) on the
corresponding digital access gateway. This value will get set to 1 (one) if the Data
Link is up (in service) or 0 (zero) if the Data Link is down (out of service).
OutboundBusyAttempts This counter represents the total number of times that a call through this MGCP
BRI device was attempted when no voice channels were available.
Table 5-21 Cisco MGCP BRI Device (continued)
Counters Counter Description
Table 5-22 Cisco MGCP FXO Device
Counters Counter Description
CallsCompleted This counter represents the total number of successful calls that were made from
the port on an MGCP FXO device.
OutboundBusyAttempts This counter represents the total number of times that a call through the port on
this MGCP FXO device was attempted when no voice channels were available.
PortStatus This counter represents the status of the FXO port that is associated with this
MGCP FXO device.
Table 5-23 Cisco MGCP FXS Device
Counters Counter Description
CallsCompleted This counter represents the total number of successful calls that were made from
this port on the MGCP FXS device.
OutboundBusyAttempts This counter represents the total number of times that a call through this port on
the MGCP FXS device was attempted when no voice channels were available.
PortStatus This counter represents the status of the FXS port that is associated with a MGCP
FXS device.
