Chapter 5 Cisco Unified Real-Time Monitoring Tool Tracing, PerfMon Counters, and Alerts
Performance Monitoring in RTMT
Cisco Music On Hold (MOH) Device
The Cisco Music On Hold (MOH) Device object provides information about registered Cisco MOH
devices. Table 5-28 contains information on Cisco MOH device counters.
Table 5-28 Cisco MOH Device
Counters Counter Description
MOHHighestActiveResources This counter represents the largest number of simultaneously active MOH
connections for an MOH server. This number includes both multicast and unicast
connections.
MOHMulticastResourceActive This counter represents the number of currently active multicast connections to
multicast addresses that are served by an MOH server.
Each MOH multicast resource uses one stream for each audio source and codec
combination. For example, if the default audio source is configured for multicast,
G.711 mu-law and wideband codecs, two streams get used (default audio source
+ G.711 mu-law and default audio source + wideband).
MOHMulticastResourceAvailable This counter represents the number of multicast MOH connections to multicast
addresses that are served by an MOH server that are not active and are still
available to be used now for the MOH server.
Each MOH multicast resource uses one stream for each audio source and codec
combination. For example, if the default audio source is configured for multicast,
G.711 mu-law and wideband codecs, two streams get used (default audio source
+ G.711 mu-law and default audio source + wideband).
MOHOutOfResources This counter represents the total number of times that the Media Resource
Manager attempted to allocate an MOH resource when all available resources on
all MOH servers that are registered with a Cisco Unified Communications
Manager were already active.
MOHTotalMulticastResources This counter represents the total number of multicast MOH connections that are
allowed to multicast addresses that are served by an MOH server.
Each MOH multicast resource uses one stream for each audio source and codec
combination. For example, if the default audio source is configured for multicast,
G.711 mu-law and wideband codecs, two streams get used (default audio source
+ G.711 mu-law and default audio source + wideband).
MOHTotalUnicastResources This counter represents the total number of unicast MOH connections that are
allowed by an MOH server.
Each MOH unicast resource uses one stream.
MOHUnicastResourceActive This counter represents the number of active unicast MOH connections to an
MOH server.
Each MOH unicast resource uses one stream.
MOHUnicastResourceAvailable This counter represents the number of unicast MOH connections that are not
active and are still available to be used now for an MOH server.
Each MOH unicast resource uses one stream.
