Further markings
The following markings are used in this manual to highlight operating instructions, results,
collections, references and other elements:
Marking Explanation
1., 2., 3. ...
Step by step operating instructions
ð
Results of the operating steps
References to sections of this manual and related documents
Collections in no set order
[Button] Controls (e.g. button, switch), indicators (e.g. signal lights)
‘Display’ Screen elements (e.g. buttons, assignment of function keys)
1.7 Transport
Please refer to the “Technical data” section for the packaging dimensions and packaging
weight
Improper transport
NOTICE!
Material damage due to improper transportation!
Transport units can fall or tip over if improperly transported.
This can cause a high degree of damage.
– Be careful when unloading the transport units on delivery and during
in-house transport in-house transport; observe the symbols and instructions
on the packaging.
– Only use the attachment points provided.
– Remove packaging just before assembly.
DANGER!
Risks when commissioning equipment which has been
damaged during
transportation.
Installation or commissioning must not take place if any transport damage is
detected when unpacking the system.
By installing/commissioning damaged components, unmanageable errors may
occur, which may lead to irreparable damage to personnel and/or the system
with the use of aggressive dosing agents.
General information
8417102264 Rev. 5-01.2019
