Ecolab EcoPro - General, Electrical Data & Torques

13.4 General data
Name
Type
00510X
Type
01
110S
Type
03003M
Type
05010M
Type
12003M
Max. metering capacity [l/h]
1)
Metering mode [low] 5 11 30 50 120
Metering mode
[high]
3.3 7.3 20 33.3 80
Min. metering capacity [l/h] 0.05 0.11 0.30 0.50 1.2
Max. metering back-pressure [MPa (bar)] 0.1 (10) 0.03 (3) 0.1 (10) 0.03 (3)
Max. stroke frequency [rpm]
2)
Metering mode [low] 171 160 162 164
Metering mode
[high]
114 107 108 109
Metering rate/stroke [ml] 50 Hz/60 Hz
2)
0.53 1.04 3.16 5.74 13.51
Reproduction accuracy [%] < ± 3
Max. conveyable viscosity
[mPas] with valves:
Standard 200 100 200 100
Spring-loaded in
metering mode [low]
500 250 500 250
Spring-loaded in
metering mode
[high]
1000 500 1000 500
Permissible ambient
temperature [°C]
4)
2 - 45
Max. suction height [mWs]
3)
V
iscosity:
up to 50 mPas 2
over 50 mPas 1
Max. suction line length [m]
V
iscosity:
up to 50 mPas 3
over 50 mPas 2
Max. suction-side pre-pressure [MPa (bar)] 0.2 (2) 0.1 (1) 0.2 (2) 0.1 (1)
Max. differential pressure, suction and pressure side
[MPa (bar)]
0.1 (1) 0.05 (0.5) 0.1 (1) 0.05 (0.5)
Min. tube Ø [mm] suction side;
viscosity:
up to 50 mPas
4
5 6 12
over 50 mPas 9 12 19
Min. hose Ø [mm] pressure
side; viscosity:
up to 50 mPas
5
5 6 9
over 50 mPas 6 9 12
Noise level [DBA] at a distance of 1 m
(according to DIN EN 12639/ EN ISO 9614-2)
< 60
Weight [kg] 3.1 3.8 5.2 5.7
Approvals CE
1)
Values calculated using water as a metering medium at a temperature of
20°C.
2)
Values vary depending on calibration.
3)
Suction heights determined with clean, moistened valves at max. stroke
frequency.
4)
Measurement in the MK240 heating cabinet.
Technical specifications
77 417102264 Rev. 5-01.2019
