Chapter 4
| Interface Configuration
Port Configuration
– 114 –
◆ When a profile is assigned to a port, any traffic attributes not defined in the
profile are subject normal switching rules.
Parameters
These parameters are displayed:
◆ Profile ID – Profile identifier. (Range: 1-26)
◆ Port – Port identifier. (Range: 1-12/28)
◆ Uplink Port Group – Port connected to an upstream interface.
◆ Isolated Port Group – Port connected to an down stream interface.
Web Interface
To assign a profile to an uplink or downlink port:
1. Click Interface, Port, Isolation.
2. Select Configure Interface from the Step List.
3. Select a profile identifier, and mark the uplink ports or downlink ports to which
that profile will the assigned.
4. Click Apply.
Figure 45: Assigning Port Isolation Profiles
