Chapter 12 | Security Measures
Access Control Lists
– 292 –
◆ Mode
■
Absolute – Specifies a specific time or time range.
■
Start/End – Specifies the hours, minutes, month, day, and year at which
to start or end.
■
Periodic – Specifies a periodic interval.
■
Start/To – Specifies the days of the week, hours, and minutes at which
to start or end.
Web Interface
To configure a time range:
1. Click Security, ACL.
2. Select Configure Time Range from the Step list.
3. Select Add from the Action list.
4. Enter the name of a time range.
5. Click Apply.
Figure 186: Setting the Name of a Time Range
To show a list of time ranges:
1. Click Security, ACL.
2. Select Configure Time Range from the Step list.
3. Select Show from the Action list.
