Chapter 2
| Using the Web Interface
Navigating the Web Browser Interface
– 44 –
commands issued through the web interface. See “Configuring Interface Settings
for STA” on page 190.
Note:
Users are automatically logged off of the HTTP server or HTTPS server if no
input is detected for 300 seconds.
Note:
Connection to the web interface is not supported for HTTPS using an IPv6
link local address.
Navigating the Web Browser Interface
To access the web-browser interface you must first enter a user name and
password. The administrator has Read/Write access to all configuration parameters
and statistics. The default user name and password for the administrator is “admin.”
Home Page When your web browser connects with the switch’s web agent, the home page is
displayed as shown below. The home page displays the Main Menu on the left side
of the screen and System Information on the right side. The Main Menu links are
used to navigate to other menus, and display configuration parameters and
statistics.
Figure 1: Home Page
Note:
This manual covers the ECS4210-12P and ECS4210-28P Gigabit Ethernet PoE
switches, as well as the ECS4210-12T and ECS4210-28T Gigabit Ethernet switches.
Other than the number of ports and support for PoE, there are no other significant
differences. Therefore nearly all of the screen display examples are based on the
ECS4210-28T. The panel graphics for all switch types are shown on the following
page.
