Chapter 13
| Basic Administration Protocols
Link Layer Discovery Protocol
– 368 –
◆ Chassis ID – An octet string indicating the specific identifier for the particular
chassis in this system.
◆ System Name – A string that indicates the system’s administratively assigned
name (see “Displaying System Information” on page 66).
◆ System Description – A textual description of the network entity. This field is
also displayed by the show system command.
◆ System Capabilities Supported – The capabilities that define the primary
function(s) of the system.
◆ System Capabilities Enabled – The primary function(s) of the system which
are currently enabled. Refer to the preceding table.
◆ Management Address – The management address protocol packet includes
the IPv4 address of the switch. If no management address is available, the
address should be the MAC address for the CPU or for the port sending this
advertisement.
Interface Settings
The attributes listed below apply to both port and trunk interface types. When a
trunk is listed, the descriptions apply to the first port of the trunk.
◆ Port/Trunk Description – A string that indicates the port or trunk description.
If RFC 2863 is implemented, the ifDescr object should be used for this field.
◆ Port/Trunk ID – A string that contains the specific identifier for the port or
trunk from which this LLDPDU was transmitted.
Table 26: System Capabilities
ID Basis Reference
Other —
Repeater IETF RFC 2108
Bridge IETF RFC 2674
WLAN Access Point IEEE 802.11 MIB
Router IETF RFC 1812
Telephone IETF RFC 2011
DOCSIS cable device IETF RFC 2669 and IETF RFC 2670
End Station Only IETF RFC 2011
