Chapter 16
| Multicast Filtering
MLD Snooping (Snooping and Query for IPv6)
– 499 –
Parameters
These parameters are displayed:
◆ VLAN – Specifies the VLAN which is to propagate the multicast service.
(Range: 1-4094)
◆ Multicast IPv6 Address – The IP address for a specific multicast service.
◆ Interface – Activates the Port or Trunk scroll down list.
◆ Port or Trunk – Specifies the interface assigned to a multicast group.
◆ Type (Show Current Member) – Shows if this multicast stream was statically
configured by the user, discovered by MLD Snooping, or is a data stream to
which no other ports are subscribing (i.e., the stream is flooded onto VLAN
instead of being trapped to the CPU for processing, or is being processed by
MVR6).
Web Interface
To statically assign an interface to an IPv6 multicast service:
1. Click Multicast, MLD Snooping, MLD Member.
2. Select Add Static Member from the Action list.
3. Select the VLAN that will propagate the multicast service, specify the interface
attached to a multicast service (through an MLD-enabled switch or multicast
router), and enter the multicast IP address.
4. Click Apply.
Figure 334: Assigning an Interface to an IPv6 Multicast Service
