Edge-Core ECS4210-12P - Figure 280: Managing a Cluster Member; Managing Cluster Members

Chapter 13 | Basic Administration Protocols
Switch Clustering
– 425 –
Managing
Cluster Members
Use the Administration > Cluster (Show Member) page to manage another switch
in the cluster.
Parameters
These parameters are displayed:
Member ID – The ID number of the Member switch. (Range: 1-36)
Role – Indicates the current status of the switch in the cluster.
IP Address – The internal cluster IP address assigned to the Member switch.
MAC Address – The MAC address of the Member switch.
Description – The system description string of the Member switch.
Operate – Remotely manage a cluster member.
Web Interface
To manage a cluster member:
1. Click Administration, Cluster.
2. Select Show Member from the Step list.
3. Select an entry from the Cluster Member List.
4. Click Operate.
Figure 280: Managing a Cluster Member
