Chapter 12
| Security Measures
Configuring 802.1X Port Authentication
– 332 –
Web Interface
To configure port authenticator settings for 802.1X:
1. Click Security, Port Authentication.
2. Select Configure Interface from the Step list.
3. Click Supplicant.
4. Modify the supplicant settings for each port as required.
5. Click Apply
Figure 214: Configuring Interface Settings for 802.1X Port Supplicant
Displaying
802.1X Statistics
Use the Security > Port Authentication (Show Statistics) page to display statistics for
dot1x protocol exchanges for any port.
Parameters
These parameters are displayed:
Table 22: 802.1X Statistics
Parameter Description
Authenticator
Rx EAPOL Start The number of EAPOL Start frames that have been received by this
Authenticator.
Rx EAPOL Logoff The number of EAPOL Logoff frames that have been received by
this Authenticator.
Rx EAPOL Invalid The number of EAPOL frames that have been received by this
Authenticator in which the frame type is not recognized.
