Chapter 6
| Address Table Settings
Setting Static Addresses
– 166 –
◆ Static addresses will not be removed from the address table when a given
interface link is down.
◆ A static address cannot be learned on another port until the address is removed
from the table.
Parameters
These parameters are displayed:
◆ VLAN – ID of configured VLAN. (Range: 1-4094)
◆ Interface – Port or trunk associated with the device assigned a static address.
◆ MAC Address – Physical address of a device mapped to this interface. Enter an
address in the form of xx-xx-xx-xx-xx-xx or xxxxxxxxxxxx.
◆ Static Status – Sets the time to retain the specified address, or to one of the
other optional modes.
■
Permanent - Assignment is permanent. (This is the default.)
■
Delete-on-reset - Assignment lasts until the switch is reset.
■
Movable Static - Refer to “Configuring Extended MAC Security.”
■
Isolation - Refer to “Configuring MAC Address Isolation.”
Web Interface
To configure a static MAC address:
1. Click MAC Address, Static.
2. Select Configure Static Address from the Step list.
3. Select Add from the Action list.
4. Specify the VLAN, the port or trunk to which the address will be assigned, the
MAC address, and the lifetime for this entry.
5. Click Apply.
Figure 91: Configuring Static MAC Addresses
