Chapter 11
| VoIP Traffic Configuration
Configuring VoIP Traffic
– 244 –
Configuring VoIP Traffic
Use the Traffic > VoIP (Configure Global) page to configure the switch for VoIP
traffic. First enable automatic detection of VoIP devices attached to the switch
ports, then set the Voice VLAN ID for the network. The Voice VLAN aging time can
also be set to remove a port from the Voice VLAN when VoIP traffic is no longer
received on the port.
Command Usage
All ports are set to VLAN access mode by default. Prior to enabling VoIP for a port
(by setting the VoIP mode to Auto or Manual as described below), first ensure that
VLAN membership is not set to access mode (see “Adding Static Members to
VLANs” on page 140).
Parameters
These parameters are displayed:
◆ Auto Detection Status – Enables the automatic detection of VoIP traffic on
switch ports. (Default: Disabled)
◆ Voice VLAN – Sets the Voice VLAN ID for the network. Only one Voice VLAN is
supported and it must already be created on the switch. (Range: 1-4094)
◆ Voice VLAN Aging Time – The time after which a port is removed from the
Voice VLAN when VoIP traffic is no longer received on the port.
(Range: 5-43200 minutes; Default: 1440 minutes)
Note:
The Voice VLAN ID cannot be modified when the global Auto Detection
Status is enabled.
Web Interface
To configure global settings for a Voice VLAN:
1. Click Traffic, VoIP.
2. Select Configure Global from the Step list.
3. Enable Auto Detection.
4. Specify the Voice VLAN ID.
5. Adjust the Voice VLAN Aging Time if required.
6. Click Apply.
