Chapter 16
| Multicast Filtering
MLD Snooping (Snooping and Query for IPv6)
– 497 –
Command Usage
MLD Snooping must be enabled globally on the switch (see “Configuring MLD
Snooping and Query Parameters” on page 494) before a multicast router port can
take effect.
Parameters
These parameters are displayed:
◆ VLAN – Selects the VLAN which is to propagate all IPv6 multicast traffic coming
from the attached multicast router. (Range: 1-4094)
◆ Interface – Activates the Port or Trunk scroll down list.
◆ Port or Trunk – Specifies the interface attached to a multicast router.
Web Interface
To specify a static interface attached to a multicast router:
1. Click Multicast, MLD Snooping, Multicast Router.
2. Select Add Static Multicast Router from the Action list.
3. Select the VLAN which will forward all the corresponding IPv6 multicast traffic,
and select the port or trunk attached to the multicast router.
4. Click Apply.
Figure 331: Configuring a Static Interface for an IPv6 Multicast Router
To show the static interfaces attached to a multicast router:
1. Click Multicast, MLD Snooping, Multicast Router.
2. Select Show Static Multicast Router from the Action list.
3. Select the VLAN for which to display this information.
