Chapter 13
| Basic Administration Protocols
Remote Monitoring
– 417
example, if control entry 15 is assigned to port 5, this index entry will be
removed from the Show and Show Details page for port 8.
Parameters
These parameters are displayed:
Port – The port number on the switch.
Index - Index to this entry. (Range: 1-65535)
Interval - The polling interval. (Range: 1-3600 seconds; Default: 1800 seconds)
Buckets - The number of buckets requested for this entry. (Range: 1-65536;
Default: 50)
The number of buckets granted are displayed on the Show page.
Owner - Name of the person who created this entry. (Range: 1-127 characters)
Web Interface
To periodically sample statistics on a port:
1. Click Administration, RMON.
2. Select Configure Interface from the Step list.
3. Select Add from the Action list.
4. Click History.
5. Select a port from the list as the data source.
6. Enter an index number, the sampling interval, the number of buckets to use,
and the name of the owner for this entry.
7. Click Apply
Figure 270: Configuring an RMON History Sample
