Chapter 13 | Basic Administration Protocols
Simple Network Management Protocol
– 391 –
Add OID Subtree
◆ View Name – Lists the SNMP views configured in the Add View page.
(Range: 1-32 characters).
◆ OID Subtree – Adds an additional object identifier of a branch within the MIB
tree to the selected View. Wild cards can be used to mask a specific portion of
the OID string. (Range: 1-64 characters).
◆ Type – Indicates if the object identifier of a branch within the MIB tree is
included or excluded from the SNMP view.
Web Interface
To configure an SNMP view of the switch’s MIB database:
1. Click Administration, SNMP.
2. Select Configure View from the Step list.
3. Select Add View from the Action list.
4. Enter a view name and specify the initial OID subtree in the switch’s MIB
database to be included or excluded in the view. Use the Add OID Subtree page
to add additional object identifier branches to the view.
5. Click Apply
Figure 247: Creating an SNMP View
To show the SNMP views of the switch’s MIB database:
1. Click Administration, SNMP.
2. Select Configure View from the Step list.
3. Select Show View from the Action list.
