Chapter 5
| VLAN Configuration
Protocol VLANs
– 155 –
2. Create a protocol group for each of the protocols you want to assign to a
VLAN using the Configure Protocol (Add) page.
3. Then map the protocol for each interface to the appropriate VLAN using
the Configure Interface (Add) page.
â—† When MAC-based, IP subnet-based, and protocol-based VLANs are supported
concurrently, priority is applied in this sequence, and then port-based VLANs
last.
Configuring Protocol
VLAN Groups
Use the VLAN > Protocol (Configure Protocol - Add) page to create protocol groups.
Parameters
These parameters are displayed:
◆ Frame Type – Choose either Ethernet, RFC 1042, or LLC Other as the frame type
used by this protocol.
◆ Protocol Type – Specifies the protocol type to match. The available options are
IP, ARP, RARP, PPPoE Discovery, PPPoE Session, and IPv6. If LLC Other is chosen
for the Frame Type, the only available Protocol Type is IPX Raw.
◆ Protocol Group ID – Protocol Group ID assigned to the Protocol VLAN Group.
(Range: 1-2147483647)
Note:
Traffic which matches IP Protocol Ethernet Frames is mapped to the VLAN
(VLAN 1) that has been configured with the switch's administrative IP. IP Protocol
Ethernet traffic must not be mapped to another VLAN or you will lose
administrative network connectivity to the switch. If lost in this manner, network
access can be regained by removing the offending Protocol VLAN rule via the
console. Alternately, the switch can be power-cycled, however all unsaved
configuration changes will be lost.
Web Interface
To configure a protocol group:
1. Click VLAN, Protocol.
2. Select Configure Protocol from the Step list.
3. Select Add from the Action list.
4. Select an entry from the Frame Type list.
5. Select an entry from the Protocol Type list.
