Factory Default Settings
Fixed Switch Configuration Guide 4-3
Password history No passwords are checked for duplication.
Policy classification Classification rules are automatically enabled when created.
Port auto-negotiation Enabled on all ports.
Port advertised ability Maximum ability advertised on all ports.
Port broadcast suppression Enabled and set to limit broadcast packets to 14,881 per second on all switch
ports.
Port duplex mode Set to half duplex, except for 100BASE-FX and 1000BASE-X, which is set to
full duplex.
Port enable/disable Enabled.
Port priority Set to 0.
Port speed Set to 10 Mbps, except for 1000BASE-X, which is set to 1000 Mbps, and
100BASE-FX, which is set to 100 Mbps.
Port trap All ports are enabled to send link traps.
Power over Ethernet port
admin state
Administrative state is on (auto).
Supported only on switches with PoE.
Priority classification Classification rules are automatically enabled when created.
RADIUS client Disabled.
RADIUS retries When the client is enabled, set to 3.
RADIUS timeout When the client is enabled, set to 20 seconds.
Rate limiting Disabled globally and on all ports. (Available only on A4 switches.)
Security mode Normal.
SNMP Enabled.
SNTP Disabled.
Spanning Tree Globally enabled and enabled on all ports.
Spanning Tree edge port
administrative status
Edge port administrative status begins with the value set to false initially after
the device is powered up. If a Spanning Tree BDPU is not received on the
port within a few seconds, the status setting changes to true.
Spanning Tree edge port
delay
Enabled.
Spanning Tree forward
delay
Set to 15 seconds.
Spanning Tree hello
interval
Set to 2 seconds.
Spanning Tree ID (SID) Set to 0.
Spanning Tree maximum
aging time
Set to 20 seconds.
Spanning Tree port priority All ports with bridge priority are set to 128 (medium priority).
Spanning Tree priority Bridge priority is set to 32768.
Table 4-1 Default Settings for Basic Switch Operation (continued)
Feature Default Setting
