Authentication Configuration Example
Fixed Switch Configuration Guide 10-27
In an 802.1x configuration, policy is specified in the RADIUS account configuration on the
authentication server using the RADIUS Filter-ID. See “The RADIUS Filter-ID” on page 8 for
RADIUS Filter-ID information. If a RADIUS Filter-ID exists for the user account, the RADIUS
protocol returns it in the RADIUS Accept message and the firmware applies the policy to the user.
The following CLI input:
• Enables EAP on the stackable fixed switch
System(rw)->set eapol enable
• Enables 802.1x on the switch
• Sets port-control to forced-auth for all connections between switches and routers, because
they do not use authentication and would be blocked if not set to forced-auth.
System(rw)->set dot1x enable
System(rw)->set dot1x auth-config authcontrolled-portcontrol forced-auth ge.1.5
System(rw)->set dot1x auth-config authcontrolled-portcontrol forced-auth
ge.1.19
System(rw)->set dot1x auth-config authcontrolled-portcontrol forced-auth
ge.2.24
This completes the 802.1x end-user stations configuration.
Configuring the Printer Cluster for MAC-Based Authentication
Perform the following tasks to configure MAC-based authentication for the printer cluster in our
example:
• Set up an account for each printer on the authentication server that contains the printer MAC
address, the MAC authentication password configured on the switch, and a RADIUS Filter-ID
entry specifying the printer policy.
• Configure a policy using NetSight Policy Manager specifying the printer cluster VLAN and
optionally configuring a CoS and rate limit.
• Enable MAC authentication globally on the switch.
• Enter the MAC authentication password as enterasys on the switch.
• Set the MAC authentication significant-bits to 24.
• Enable MAC authentication on the ports used by the printer cluster: ge.1.3-4
With the authentication server configured with a RADIUS account for each printer, and the printer
policy pre-configured, enter the following CLI input:
System(rw)->set macauthentication enable
System(rw)->set macauthentication password enterasys
System(rw)->set macauthentication significant-bits 24
System(rw)->set macauthentication port enable ge.1.3-4
This completes the printer cluster MAC authentication configuration.
Note: Globally enabling 802.1x on a switch sets the port-control type to auto for all ports. Be sure to
set port-control to forced-auth on all ports that will not be authenticating using 802.1x and no other
authentication method is configured. Otherwise these ports will fail authentication and traffic will be
blocked.
