Using the Equipment
To access this menu from the above menu, press the (Down) key.
SOURCE 1 |MAPPING MODE (S2 ONLY)
3.2.2.9 |MEAN POWER (UNLOCKED)
Use the (Up) and (Down) keys to select ENABLE or DISABLE.
3.10.4.7.11 Gold Sequence
The gold sequence code is the seed for a randomizing sequence which can be used
to uniquely identify the owner of the transmission. The satellite input will only lock to
the incoming signal when the gold code entered into the IRD matched the code set
in the up-link modulator. For this reason, the Gold Sequence will often be used as a
form of fixed key CA.
To access this menu from the above menu, press the (Down) key.
SOURCE 1 |GOLD SEQ N (s2 ONLY)
3.2.2.10 |000000 (UNLOCKED)
Use the (Up) and (Down) keys to select ENABLE or DISABLE.
3.10.4.7.12 LNB Power
Allows the user to ENABLE/DISABLE power to the LNB.
This menu allows different LNB voltages to be set:
- 13 V (Vertical polarization)
- 18 V (Horizontal polarization)
- Boosted 13 V (Vertical polarization)
- Boosted 18 V (Horizontal polarization)
Note: The Boosted options increase the voltage slightly to account for voltage
drop that occurs down long cable runs from the IRD to the LNB. This feature
is not supported by the DVB-S2X card.
To access this menu from the above menu, press the (Down) key.
SOURCE 1 |LNB POWER LEVEL
3.2.2.11 |13V (VERT) (UNLOCKED)
Use the (Up) (Down) keys to select the required value from the available
options.
