Using the Equipment
The following fields are available on this dialog box.
• User Name – Used to enter the new desired user name.
• Old Password – Used to enter the current password.
• New Password – Used to enter the new desired password.
• Confirm New Password – Used to confirm the new desired password.
In order to change the XPO password, all four of these fields must be populated
before clicking on Apply Changes.
3.11.8.5.3 Conax CA Specific Functionality
3.11.8.5.3.1 Fingerprint OSD Message
The RX8330C supports Conax fingerprint messages which are protected by the Link
Protection security feature. No configuration is required for this.
The Finger print message is always displayed as white text with transparent
background. The operator can specify its start time, its duration and what area on
the screen it shall be displayed.
3.11.8.5.3.2 User Text OSD Message
This feature is not supported by the RX8330C.
3.11.8.5.4 Menu Options
All the Conax CA specific information is located under the CA tab via the web
browser under the section Conax Conditional Access. Some of the status
information may be found under the front panel menu: CA Systems > Conax
(menu ID 5.2 as of release version 10.0.0).
3.11.8.5.4.1 Current Status
This specifies what the current Conax CA status is, all available status messages
and their meaning are listed in section 3.11.8.5.7. Where there are no errors
detected by the CA system then this field is left blank.
Figure 3.81 Conax ‘Current Status’ Dialog Box
3.11.8.5.4.2 Maturity Lock Override
This field is used to enter the correct CA PIN of the smart card in use to override the
Maturity Lock (see section 3.11.8.5.6).
