Using the Equipment
EN/LZT 790 0005 R7A
3-97
3.10.5.13.41 Failover Mode Switch
This menu enables the viewing and editing of the Failover Mode Switch. To access
this menu from the above menu, press the  (Down) key.
I/P PORT |FAILOVER MODE SWITCH
3.2.5.3 |INTERFACES ONLY
Use the  (Up) and  (Down) keys to toggle between the Interfaces and Streams
and Interfaces Only.
3.10.5.13.42 Stream 1/Unicast Enable 1
This menu allows the enabling of Unicast and provides sub-menus to further control
parameters. To access this menu from the above menu, press the  (Down) key.
STREAM 1 |UNICAST ENABLE 1
3.2.6 |TRUE >
Use the  (Up) and  (Down) keys to toggle between the True and False options.
3.10.5.13.43 MCAST IP Address 1
This menu enables the viewing and editing of the Multicast IP address. To view and
edit the MCAST IP Address 1, press the  (Forward) key.
STREAM 1 |MCAST IP ADDRESS 1
3.2.6.1 |000.000.000.000
Use the  (Up),  (Down),  (Forward) and  (Back) keys to enter the address.
3.10.5.13.44 Source IP Address 1
This menu enables the viewing and editing of source IP address. To access this
menu from the above menu, press the  (Down) key.
STREAM 1 |SOURCE IP ADDRESS 1
3.2.6.2 |000.000.000.000
Use the  (Up),  (Down),  (Forward) and  (Back) keys to enter the address.
3.10.5.13.45 UDP Port 1
This menu enables the viewing and editing of UDP Port 1. To access this menu from
the above menu, press the  (Down) key.
