• IP output
• CVBS
• CVBS with support for Russian SECAM
• VGA output
• Analogue audio.
• RS232 data
Table 3.53 RX8000 Card and Output Types
Card type Output type Port(s)
Russian SECAM analog 2 BNC 75 Ohm
IP output digital 2 Ethernet RJ45
HD output digital 3 BNC + 1 serial port
Audio output analog/digital 2 DB9 ports
3.18.1 Asynchronous Serial Interface (ASI) Output
 = Option B = Supplied with Base Model
RX8200 RX8252 RX8305 RX8310 RX8310B RX8315 RX8320 RX8330 RX8330C
B B B B B B B B
3.18.1.1 Order Items
Option Name Card Number FAZ Number Marketing Code
RX8200/HWO/SD S16075 FAZ 101 0113/18 RX8200/HWO/SD
RX8200/HWO/HD S14993 FAZ 101 0113/9 RX8200/HWO/HD
RX8200/HWO/HD/3G S15145 FAZ 101 0113/10 RX8200/HWO/HD/3G
3.18.1.2 Control
Web Front
Panel
SNMP Serial Remote
   
