Ericsson RX8000 - Digital Video Output Connectors; HD SDI Digital Video; SD SDI Digital Video; Sync Output Specification

Technical Specification
B-10
EN/LZT 790 0005 R7A
Table B.6 Sync Output Specification
Parameter Value Condition Notes
H and V sync. high voltage >2.5 V
2.2 kΩ
H and V Sync. low voltage <0.5 V
2.2 kΩ
B.1.1.6 SD SDI Digital Video
Table B.7 Digital Video Output Connectors
Item Specification
Safety status SELV
Connector type
BNC, female, 75 Ω
Connector designation SDI 1
SDI 2
SDI 3
Output standard (USA) ANSI/SMPTE 259M
SDI output level
800 mV pk-pk nominal ±10%
Jitter performance, nominal SMPTE Recommended Practices RP 192 –1996
Jitter Measurement Procedures in Bit-Serial
Digital Interfaces
B.1.1.7 HD SDI Digital Video
Table B.8 Digital Video Output Connectors
Item Specification
Safety status SELV
Connector type
BNC, female, 75 Ω
Connector designation HD SDI 1
HD SDI 2
HD SDI 3
Output standard (USA) ANSI/SMPTE 292M
SDI output level
800 mV pk-pk nominal ±10%
Jitter performance, nominal SMPTE Recommended Practices RP 192 –1996
Jitter Measurement Procedures in Bit-Serial
Digital Interfaces
