Ericsson RX8000 - Serial Digital Interface (SDI) Output

Using the Equipment
3-338
EN/LZT 790 0005 R7A
3.18.2 Serial Digital Interface (SDI) Output
 = Option B = Supplied with Base Model
RX8200 RX8252 RX8305 RX8310 RX8310B RX8315 RX8320 RX8330 RX8330C
SDI B B 

HD-SDI 
3G-SDI 
3.18.2.1 Order Items
Option Name Card Number FAZ Number Marketing Code
RX8200/HWO/SD S16075 FAZ 101 0113/18 RX8200/HWO/SD
RX8200/HWO/HD S14993 FAZ 101 0113/9 RX8200/HWO/HD
RX8200/HWO/HD/3G S15145 FAZ 101 0113/10 RX8200/HWO/HD/3G
3.18.2.2 Control
Web Front Panel SNMP Serial Remote
   
3.18.2.3 License Keys
Marketing Code Description FAZ Number License Key Name
RX83XX/SWO/SDI SDI Output Capability FAZ 101 0108/35 RX83XX/SWO/SDI
3.18.2.4 Functional Description
SD-SDI is used to transport baseband digital video at SD resolutions.
HD-SDI is used to transport baseband digital video at HD resolutions such as 720p
and 1080i.
3G-SDI is used to transport baseband digital video at higher rate HD resolutions
such as 1080p.
3.18.2.5 SDI Output Capabilities on the RX8300
The RX8300 series has two SDI connectors where fitted.
