Ericsson RX8000 - Auxiliary Data; VBI and VANC Data

Using the Equipment
EN/LZT 790 0005 R7A
3-283
3.17 Auxiliary Data
3.17.1 VBI and VANC Data
3.17.1.1 Availability
 = Option B = Supplied with Base Model
RX8200 RX8252 RX8305 RX8310 RX8310B RX8315 RX8320 RX8330 RX8330C
VBI
B B B B B B B B B
VANC
B B
SD VANC
B B
3.17.1.2 Order Items
Option Name Card Number FAZ Number Marketing Code
There are no order items available
3.17.1.3 Control
Web Front
Panel
SNMP Serial Remote




3.17.1.4 License Keys
Marketing Code Description FAZ Number License Key Name
There are no license keys associated with this functionality.
3.17.1.5 Functional Description
All RX8000 variants support outputting Vertical Blanking Interval (VBI) data in to the
composite video and SD-SDI video. In addition, RX8200 variants support outputting
Vertical Ancillary (VANC) data in to the HD-SDI video as well as some limited data
types in to the SD-SDI video.
3.17.1.5.1 Data Type Order of Precedence
Some data types can be sourced from multiple data paths. Where a data type is
available or repeated in different sources, the RX8000 will source the data from the
following list in order of precedence:
