Ericsson RX8000 - FEC Block Error Rate; MER;MER Margin; OFDM Symbol Rate; TS Lock in Demodulator

Using the Equipment
EN/LZT 790 0005 R7A
3-125
This BER is shown in dB.
3.10.7.11.10 MER
This menu shows the pre Modulation Error Ratio.
STATUS |MER
3.2.1.10 |30
This MER is shown in dB.
3.10.7.11.11 MER Margin
This menu shows the MER margin above failure.
STATUS |MER MARGIN
3.2.1.11 |30
This MER margin is shown in dB.
3.10.7.11.12 FEC Block Error Rate
This menu shows the FEC Block Error Rate.
STATUS |FEC BLOCK ERROR RATE
3.2.1.12 |30
This FEC block error rate is shown in dB.
3.10.7.11.13 OFDM Symbol Rate
This menu shows the OFDM Symbol Rate.
STATUS |OFDM SYMBOL RATE
3.2.1.13 |30
This FEC block error rate is shown in MSym/s.
3.10.7.11.14 TS Lock in Demodulator
This menu shows the lock state of the demodulator.
STATUS |TS LOCK IN DEMODULATOR
3.2.1.14 |NOT DETECTED
This can have the values:
• NOT DETECTED
