Ericsson RX8000 - LNB Power and Control

Technical Specification
B-24
EN/LZT 790 0005 R7A
Parameter Specification
Phase noise SSB (single sideband)
DVB-S2 with pilots on only:
QPSK > 10-45 MSymbol/s
8PSK > 10-45 MSymbol/s
(free running DRO)
< -35 dBc/Hz at δF = 10 Hz
< -63 dBc/Hz at δF = 100 Hz
< -85 dBc/Hz at δF = 10 kHz
< -90 dBc/Hz at δF = 100 kHz
< -90 dBc/Hz at δF = 1 MHz
< -96 dBc/Hz at δF = 1 MHz
< -108 dBc/Hz at δF = >10 MHz
δF = Frequency offset from carrier
Phase noise SSB (single sideband)
DVB-DSNG/S:
QPSK > 5 MSymbol/s
8PSK > 22 MSymbol/s
16QAM > 6 MSymbol/s
(free running DRO)
< -35 dBc/Hz at δF = 10 Hz
< -63 dBc/Hz at δF = 100 Hz
< -85 dBc/Hz at δF = 10 kHz
< -90 dBc/Hz at δF = 100 kHz
< -90 dBc/Hz at δF = 1 MHz
< -96 dBc/Hz at δF = 1 MHz
< -108 dBc/Hz at δF = >10 MHz
δF = Frequency offset from carrier
LNB power and control
See Table B.24.
For more detailed specification information and advice on performance in specific
applications, please contact Ericsson Customer Services.
B.2.2.2 LNB Power and Control
The RX8000 supports voltage controlled LNBs only. The active input is selectable
and can provide DC power and frequency band selection signals compatible with
most professional and commercial LNBs. The LNB power is made available on only
one of its L-band inputs (F-type connector) and its power characteristics comply with
IEC 1319-1 and are as per Table B.24.
Table B.24 LNB Power and Control
Parameter Specification
Voltage V (nominal) Receiver Polarisation
Voltage 13
18
Vertical/circular right
Horizontal/circular left
Current 350 mA maximum
LNB control
22 ± 4 kHz tone
