3.10.7.11.19 FFT Size in TPS
This menu shows the currently used FFT (Fast Fourier Transform) size shown within
the TPS (Transmission Parameter Signaling).
STATUS |FFT IN TPS
3.2.1.1.2 |0
3.10.7.11.20 Guard Interval in TPS
This menu shows the guard interval signaled within the TPS signaling.
STATUS |GUARD INTERVAL
3.2.1.1.3 |1/32
This can have the values:
• 1/32
• 1/16
• 1/8
• 1/4
3.10.7.11.21 TPS Constellation
This menu shows the constellation signaled within the TPS.
STATUS |CONSTELLATION
3.2.1.1.4 |16 QAM
This can have the values:
• QPSK
• 16QAM
• 64QAM
3.10.7.11.22 TPS High Priority Stream Code Rate
This menu shows the code rate of the high priority stream signaled by the TPS.
STATUS |HIGH PRIORITY STREAM CODE RATE
3.2.1.1.5 |1/2
This can have the values:
• 1/2
