Using the Equipment
EN/LZT 790 0005 R7A
3-277
Three audio decoders are available in this mode after enabling the
RX8200/SWO/4AUD license but it is only the Audio 1 decoder that can provide the
8-channel output. The following tables show the available output channels on
RX82xx and those not available on the RX83xx.
Table 3.44 Output Channels Available on RX82xx
RX82xx Disable 4AUD license Enable 4AUD license
Audio Decoder 1 1 3 4
Physical
decoder
Advanced Advanced Basic Basic
Output
Channels
8 8 2 2
Channel Name (AES3 Ch 1+2)
(AES3 Ch 3+4)
(AES3 Ch 5+6)
(AES3 Ch 7+8)
(AES3 Ch 1+2)
(AES3 Ch 3+4)
(AES3 Ch 5+6)
(AES3 Ch 7+8)
L R
(Stereo)
L R
(Stereo)
Table 3.45 Output Channels Available on RX83xx
RX83xx Disable 4AUD license Enable 4AUD license
Audio Decoder 1 2 N/A
Physical decoder Basic Basic
Output Channels N/A N/A
Mode N/A N/A
Under the Decode > Audio Output Routing section, the user is presented with the
following options for both the analogue outputs and the SDI embedded outputs:
• Audio 1, AES3 Ch 1+2
• Audio 1, AES3 Ch 3+4
• Audio 1, AES3 Ch 5+6
• Audio 1, AES3 Ch 7+8
• Audio 2, STEREO (available with 4AUD license).
• Audio 3, STEREO (available with 4AUD license).
3.15.9 Channel Configuration: 16 Channel Aligned (MUS only) Audio
3.15.9.1 Availability
