Ericsson RX8000 - 8-VSB Terrestrial Receivers; DVB-ASI Input

Technical Specification
EN/LZT 790 0005 R7A
B-25
B.2.3 8-VSB Terrestrial Receivers
Table B.25 8-VSB Receiver Input Specification
Parameter Specification
RF input
Safety status TNV - 1
Number of inputs 1
Input connector type
F-type, female 75 Ω
Input impedance
75 Ω
VSWR 5
Maximum input level -5 dBm
Minimum input level -80 dBm
RF Frequency
Tuning range Fc = 54 to 863 MHz
Tuning step 1 kHz
LO phase noise Min 92 dBc/Hz at 100 kHz offset
Channel bandwidth 6 MHz
FEC 2/3 Trellis
Bit rate 19.39 Mbps
Maximum input level -5 dBm
Minimum input level -80 dBm
B.2.4 DVB-ASI Input
Table B.26 DVB-ASI Copper
Input Specification
Safety status SELV
Connector type BNC, female
Input impedance
75 Ω
Data rate range 0.350 - 210 Mbps
Error decoding None
