3.13.4.5.5 Video Conversion Tables
The RX8000 can manipulate the decoded video stream on the incoming service,
either up-converting or down-converting the video to a different resolution on the
output. The Base Decoder is capable of both up-conversion and down-conversion
whereas the 4:2:2 Decoder Option card is only capable of down-conversion. Down-
conversion options are extended where High Quality Down-conversion Card is fitted.
Table 3.17 Video Conversion Running on the Base Decoder
Output Mode
Base Decoder: Input Video
SD 720p 1080i 1080p
AUTO
SD 720p 1080i -
SD
SD SD
*
SD
*
-
720p
720p
†
720p 720p
*
-
1080i
1080i
†
1080i
†
1080i -
1080p
- - - -
Key: * Down-conversion license required † Up-conversion license required
Table 3.18 Video Conversion Running on the Base Decoder with the High Quality
Down-conversion Card Fitted
Output Mode
Base Decoder + HQ Down Converter: Input Video
SD 720p 1080i 1080p
AUTO
SD 720p 1080i -
SD
SD SD
*
SD
*
-
720p
720p
†
720p 720p
*
-
1080i
1080i
†
1080i
†
1080i -
1080p
- - - -
Key: * Down-conversion license required † Up-conversion license required
Table 3.19 Video Conversion Running on the 4:2:2 Decoder Option Card
Output Mode
4:2:2 Decoder: Input Video
SD 720p 1080i 1080p
AUTO
SD 720p 1080i 1080p
SD
SD SD
*
SD
*
SD
*
720p
- 720p - -
1080i
- - 1080i 1080i
*
1080p
- - - 1080p
Key: * Down-conversion license required
