Using the Equipment
3.10.5.13.55 Port 1/ 2 Net Util
This menu displays the alarm status for IP Input Card Port 1 and Port 2 network
utilization. To access this menu from the above menu, press the (Down) key.
ALARMS |PORT 1 NET UTIL
3.2.8.6 |PORT 2 NET UTIL
3.10.5.13.56 MDI Delay Factor/ MDI Loss Rate
This menu displays the alarm status for IP Input Card Port 1 and Port 2 MDI Delay
Factor/ MDI Loss Rate. To access this menu from the above menu, press the
(Down) key.
ALARMS |MDI DELAY FACTOR
3.2.8.7 |MDI LOSS RATE
To return to the top level Alarm screen, press the (Back) key.
3.10.5.13.57 Version
This menu displays the software version for the IP Input Card and provides sub-
menus for further information. To access this menu from the above menu, press the
(Down) key.
VERSION |SOFTWARE VERSION
3.2.9 |0.13 >
3.10.5.13.58 Firmware SW Version
This menu displays the firmware version for the IP Input Card. To access this menu
from the above menu, press the (Forward) key.
VERSION |FIRMWARE SW VERSION
3.2.9.1 |0.77
3.10.5.13.59 CPLD SW Version
This menu displays the CPLD version for the IP Input Card. To access this menu
from the above menu, press the (Down) key.
VERSION |CPLD SW VERSION
3.2.9.2 |1.2
