Ericsson RX8000 - 3 G SDI Digital Video; Audio Decoding and Output Stage; General

Technical Specification
EN/LZT 790 0005 R7A
B-11
B.1.1.8 3G SDI Digital Video
Table B.9 Digital Video Output Connectors
Item Specification
Safety status SELV
Connector type
BNC, female, 75 Ω
Connector designation 3G SDI 1
3G SDI 2
3G SDI 3
Output standard (USA) ANSI/SMPTE 424M
SDI output level
800 mV pk-pk nominal ±10%
Jitter performance, nominal SMPTE Recommended Practices RP 192 –1996
Jitter Measurement Procedures in Bit-Serial
Digital Interfaces
B.1.2 Audio Decoding and Output Stage
B.1.2.1 General
The RX8000 Integrated Receiver/Decoder is capable of simultaneously decoding at
least two PES streams of audio from the Transport Stream. Each of the decoders
are identical in operation, but act independently of the other.
Each channel supports extraction of the following types of coded audio from the
Transport Stream as follows:
• MPEG-1, Layer 2 Audio (Musicam): ISO/IEC 13818-3
• Dolby Digital AC-3 Audio: ATSC document A/52
• AAC Audio
• HE-AAC Audio
• Linear Audio
• Dolby E pass-thru
• Enhanced Dolby Digital pass-thru
Audio component selection is automatic or may be specified from the User Interface
or remote interfaces. The RX8000 Integrated Receiver/Decoder automatically
detects the audio type of the selected audio component and applies the appropriate
algorithm. Audio component selection is based on the position of the component
descriptor in the PMT. Audio 1 takes the first component and Audio 2 the second.
These may be overridden by selecting User-specified component PIDs.
