Using the Equipment
3-272
EN/LZT 790 0005 R7A
Table 3.39 Paired Audio Decoder Output Mode on RX8200
RX82xx Disable 4AUD license Enable 4AUD license
Audio Decoder 1 Hide 1 Hide 2L 2R 3 Hide 4 Hide
Physical decoder Adv Adv Adv Adv Adv Adv Adv Adv Adv Adv
Output Channels 2 0 2 0 1 1 2 0 2 0
Channel Name L+R - L+R - L R L+R - L+R -
Paired Decoder
Output Mode
L+R L+R L+R L+R L+R
Table 3.40 Paired Audio Decoder Output Mode: Not Available on RX83xx
RX83xx Disable 4AUD license Enable 4AUD license
Audio Decoder 1 2 N/A
Physical decoder Basic Basic
Output Channels N/A N/A
Channel Name N/A N/A
In order to create a paired decoder, the user can split an existing decoder in the
Decode > Audio Output Routing > Create Paired Decoder section.
