Using the Equipment
SDP |SDP INSERTION
7.1.2.5.2 |
3.17.1.7.14 Multi
This menu provides the sub-menus for viewing the status of VANC Multi packets in
the incoming stream and outgoing video
3.17.1.7.15 Multi Packet Insertion
This menu enables or disables the insertion of the VANC Multi packets into the
VANC space of the HD-SDI output.
SDP |MULTI PACKET INSERTION
7.1.2.6.1 |
3.17.1.7.16 Multi Packet Stream Status
Displays the presence of VANC Multi packets in the incoming VANC PES stream.
SDP | MULTI PACKET STREAM STATUS
7.1.2.6.2 |
3.17.1.7.17 Multi Packet Output Status
Displays the presence of VANC Multi packets (OP47 Closed Captions/ Subtitling
data) in the VANC space of the HD-SDI output.
SDP | MULTI PACKET OUTPUT STATUS
7.1.2.6.3 |
3.17.1.7.18 Closed Caption
This menu provides the sub menu for selection and insertion of closed captions in
VBI as well as VANC. Also shows the status of the closed captions in the incoming
stream and output video.
VBI-VANC |CLOSED CAPTIONS
7.1.3 | >
