3: Functions and features Model 2450 Interactive SourceMeter® Instrument
Reference Manual
3-22 2450-901-01 Rev. B/September 2013
Using SCPI commands to save or append buffer content to files:
Before using any of these commands, insert a USB flash drive into the USB port.
To save readings and formatted timestamps from the default buffer to a file named myData.csv on
a USB flash drive, send the following command:
TRACe:SAVE "/usb1/myData.csv", "defbuffer1"
To save readings and formatted timestamps from a reading buffer named testData to a file named
myData.csv on a USB flash drive, send the following command:
TRACe:SAVE "/usb1/myData.csv", "testData"
To append readings and formatted timestamps from a reading buffer named testData to a file
named myData.csv on a USB flash drive, send the following command:
TRACe:SAVE:APPend "/usb1/myData.csv", "testData"
To append readings and formatted timestamps from a reading buffer named testData from point 6
to point 10 in file named myData.csv on a USB flash drive, send the following command:
TRACe:SAVE:APPend "/usb1/myData.csv", "testData", FORM, 6, 10
Using TSP commands to save or append buffer content to files:
Before using any of these commands, insert a USB flash drive into the USB port.
To save readings from the default buffer to a file named myData.csv on a USB flash drive, send the
following command:
buffer.save(defbuffer1, "/usb1/myData.csv")
To save readings from a reading buffer named testData to a file named myData.csv on a USB
flash drive, send the following command:
buffer.save(testData, "/usb1/myData.csv")
To append readings from a reading buffer named testData with default time information to a file
named myData.csv on the USB flash drive, send the following command:
buffer.saveappend(testData, "/usb1/myData.csv")
Setting buffer capacity and fill mode
To configure the buffer, you need to make the following settings:
• Setting the buffer capacity
• Setting the buffer fill mode
Buffer capacity
The initial buffer capacity for user-defined buffers is set when the buffer is created. You can resize a
user-defined buffer.
The initial buffer capacity for defbuffer1 and defbuffer2 is 10,000 readings. You can resize the
default buffers.
Stored readings and statistics are deleted when you change the capacity of a buffer.

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
