Keithley 2450 User Manual

Section
3: Functions and features Model 2450 Interactive SourceMeter® Instrument
Reference Manual
3-36 2450-901-01 Rev. B/September 2013
Instrument settings stored in a measure configuration list
When you save a configuration point to a measure configuration list, the instrument saves the values
for each setting listed in the following table. These settings can be set from the front panel or by using
remote commands. The table shows front panel, TSP, and SCPI settings that can be used to set
these settings.
Measure configuration list settings
Front-panel setting TSP command SCPI command
Function
FUNCTION key
smu.measure.func (on page 8-
103)
[:SENSe[1]]:FUNCtion[:ON] (on page 6-49
)
Auto range
HOME > Range
smu.measure.autorange (on page
8-86)
[:SENSe[1]]:<function>:RANGe:AUTO (on page
6-50)
Auto range low
MENU > Measure > Settings > Auto
Range Low Limit
smu.measure.autorangelow (on
page 8-88)
[:SENSe[1]]:<function>:RANGe:AUTO:LLIMit (on
page 6-51)
Display digits
SETTINGS swipe screen > Display
Digits
smu.measure.displaydigits (on
page 8-100)
:DISPlay:<function>:DIGits (on page 6-23)
Filter
MENU > Measure > Filter/Math > Filter
State
smu.measure.filter.enable (on
page 8-101)
[:SENSe[1]]:<function>:AVERage[:STATe] (on
page 6-44)
Filter type
MENU > Measure > Filter/Math >
Filter State Type
smu.measure.filter.type
(on page
8-102)
[:SENSe[1]]:<function>:AVERage:TCONtrol (on
page 6-45)
Filter count
MENU > Measure > Filter/Math > Filter
Count
smu.measure.filter.count (on
page 8-100)
[:SENSe[1]]:<function>:AVERage:COUNt (on
page 6-43)
NPLC
SETTINGS swipe screen > NPLCs
smu.measure.nplc (on page 8-
116)
[:SENSe[1]]:<function>:NPLCycles (on page 6-
48)
Offset compensation
MENU > Measure > Settings > Offset
Comp (when function is set to source
current and measure resistance)
smu.measure.offsetcompensation
(on page 8-117)
[:SENSe[1]]:<function>:OCOMpensated (on
page 6-49)
Relative offset
SETTINGS swipe > Rel
smu.measure.rel.enable (on page
8-121)
[:SENSe[1]]:<function>:RELative:STATe (on
page 6-57)
Relative offset value
Not available from front panel
smu.measure.rel.level (on page
8-122)
[:SENSe[1]]:<function>:RELative:ACQuire
(on
page 6-56)
Terminals
TERMINALS button
smu.measure.terminals (on page
8-124)
:ROUTe:TERMinals (on page 6-35)
Autozero enable
MENU > Measure > Settings > Auto
Zero
smu.measure.autozero.enable
(on page 8-89)
[:SENSe[1]]:<function>:AZERo[:STATe]
(on
page 6-46)
Math
MENU > Measure > Filter/Math > Math
State
smu.measure.math.enable (on
page 8-111)
:CALCulate[1]:<function>:MATH:STATe (on
page 6-12)
Math format
MENU > Measure > Filter/Math > Math
Function
smu.measure.math.format (on
page 8-112)
:CALCulate[1]:<function>:MATH:FORMat (on
page 6-7)
Math mx+b b factor
MENU > Measure > Filter/Math > b
(Offset)
smu.measure.math.mxb.bfactor
(on page 8-113)
:CALCulate[1]:<function>:MATH:MMFactor (on
page 6-10)
