Keithley 2450 User Manual

Section
3: Functions and features Model 2450 Interactive SourceMeter® Instrument
Reference Manual
3-42 2450-901-01 Rev. B/September 2013
If you want to recall a point on a source configuration list, under Source, select Config List.
3. Choose Select List. A menu of available configuration lists is displayed.
4. Select MyMeasList. The configuration points in the list display.
5. Select the second configuration point.
6. Select List to System.
7. Select HOME to return to the operating display.
Viewing configuration list contents
For example, use the following procedure to view configuration point 2 from MyMeasList.
Using the front panel to view configuration list contents:
1. Press the MENU key.
2. Under Measure, select Config List. The MEASURE CONFIGURATION LISTS screen is
displayed.
If you want to view a source configuration list, under Source, select Config List.
3. Choose Select List. A menu of available configuration lists is displayed.
4. Select MyMeasList. The configuration points are displayed.
5. Select the second configuration point.
6. Select View Details.
7. When you are finished, select OK.
8. Select HOME to return to the home screen.
Deleting a configuration point
For example, use the following procedure to delete configuration point 4 from MyMeasList.
Using the front panel to delete a configuration point:
1. Press the MENU key.
Under Measure, select Config List. The MEASURE CONFIGURATION LISTS screen is
displayed.
If you want to delete a point from a source configuration list, under Source, select Config List.
2. Choose Select List. A menu of available configuration lists is displayed.
3. Select MyMeasList. The configuration points are displayed.
4. Select the second configuration point.
5. Select Delete From.
6. Select HOME to return to the operating display.

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
