Keithley 2450 User Manual

Section
3: Functions and features Model 2450 Interactive SourceMeter® Instrument
Reference Manual
3-86 2450-901-01 Rev. B/September 2013
Diode grading SCPI code
*RST
SOUR:CONF:LIST:CRE "SOURCE_LIST"
SENS:CONF:LIST:CRE "MEASURE_LIST"
SENS:FUNC "VOLT"
SOUR:FUNC CURR
SENSe:RESistance:RSENse ON
SENS:NPLC 1
SENS:VOLT:RANG 2.4
SOUR:CURR:RANG 1
SOUR:CURR 1
SOUR:CURR:VLIM 2.4
SOUR:CURR:DEL:USER1 0.001
SOUR:CONF:LIST:STORE "SOURCE_LIST"
CALC2:LIM1:STAT ON
CALC2:LIM1:LOW 0
CALC2:LIM1:UPP 1.2
SENS:CONF:LIST:STORE "MEASURE_LIST"
SENS:FUNC "VOLT"
SOUR:FUNC CURR
SYST:RSEN ON
SENS:NPLC 1
SENS:VOLT:RANG 9.4
SOUR:CURR:RANG -0.26
SOUR:CURR -0.26
SOUR:CURR:VLIM 9.4
SOUR:CURR:DEL:USER1 0.001
SOUR:CONF:LIST:STORE "SOURCE_LIST"
CALC2:LIM1:STAT ON
CALC2:LIM1:LOW -5.17
CALC2:LIM1:UPP -4.23
SENS:CONF:LIST:STORE "MEASURE_LIST"
SENS:FUNC "CURR"
SOUR:FUNC VOLT
SYST:RSEN ON
SENS:NPLC 1
SENS:CURR:RANG 30e-6
SOUR:VOLT:RANG -1.5
SOUR:VOLT -1.5
SOUR:VOLT:ILIM 30e-6
SOUR:VOLT:DEL:USER1 0.01
SOUR:CONF:LIST:STORE "SOURCE_LIST"
CALC2:LIM1:STAT ON
CALC2:LIM1:LOW -15e-6
CALC2:LIM1:UPP 0
SENS:CONF:LIST:STORE "MEASURE_LIST"
SOUR:CONF:LIST:SIZE? "SOURCE_LIST"
SOUR:CONF:LIST:QUERY? "SOURCE_LIST"
SENS:CONF:LIST:SIZE? "MEASURE_LIST"
SENS:CONF:LIST:QUERY? "MEASURE_LIST"
TRAC:POIN 30

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
