Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 3:
Functions and features
2450-901-01 Rev. B/September 2013 3-87
DIG:LINE1:MODE DIG, OUT
DIG:LINE2:MODE DIG, OUT
DIG:LINE3:MODE DIG, OUT
DIG:LINE4:MODE DIG, OUT
DIG:LINE5:MODE TRIG, IN
TRIG:DIG5:IN:EDGE FALL
DIG:LINE6:MODE TRIG, OUT
TRIG:DIG6:OUT:LOG NEG
TRIG:DIG6:OUT:PULS 10e-6
TRIG:DIG6:OUT:STIM NOT1
TRIG:LOAD:EMPT
TRIG:BLOC:BUFF:CLE 1, "defbuffer1"
TRIG:BLOC:WAIT 2, DIG5
TRIG:BLOC:CONF:RECALL 3, "SOURCE_LIST"
TRIG:BLOC:CONF:RECALL 4, "MEASURE_LIST"
TRIG:BLOC:SOUR:STAT 5, ON
TRIG:BLOC:DEL:DYN 6, SOUR1
TRIG:BLOC:MEAS 7, "defbuffer1"
TRIG:BLOC:SOUR:STAT 8, OFF
TRIG:BLOC:DIG:IO 10, 14, 15
TRIG:BLOC:BRAN:LIM:DYN 9, IN, 1, 12, 7
TRIG:BLOC:BRAN:ALW 11, 16
TRIG:BLOC:CONF:NEXT 12, "SOURCE_LIST"
TRIG:BLOC:CONF:NEXT 13, "MEASURE_LIST"
TRIG:BLOC:BRAN:COUN 14, 3, 5
TRIG:BLOC:DIG:IO 15, 1, 15
TRIG:BLOC:DEL:CONS 16, 0.001
TRIG:BLOC:DIG:IO 17, 0, 15
TRIG:BLOC:NOT 18, 1
TRIG:BLOC:BRAN:COUN 19, 10, 2

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
